“In many cases, an HVAC system must be specially built and use a combination of explosion proof, intrinsically safe and non-incindive equipment to address flammable or ignitable substances, and it may also require integrated chemical filtration systems to prevent corrosive and toxic substances from being recirculated or introduced to a room or building from what would otherwise be considered as a fresh air or make-up air source,” said Baucom, who wrote the recently released ASHRAE Guide for HVAC in Hazardous Spaces.
Explosion-proof HVAC/ Pressurized Air Conditioning Units are mainly composed of explosion-proof integral air-conditioning units, air ducts, explosion-proof dampers and explosion-proof control boxes. The unit introduces the air in the cabin into the air conditioning system through the air duct for circulation, and supplements fresh air from the safe area to ensure the normal positive pressure value in the analysis room. The unit mixes the return air with the fresh air and processes it into comfortable air and sends it into the analysis room, and ensures that the positive pressure range in the room is between 25-75Pa (adjustable).
Applications
- Reliable explosion-proof performance, compact structure, convenient operation and beautiful appearance.
- For hazardous gas areas as Zone 1&2, where need units with refrigeration, dehumidification, heating, Ventilation, maintaining indoor positive pressure and other functions.
- Applicable to petroleum, chemical, pharmaceutical and other industries where there are flammable and explosive gas instrument control rooms, laboratories, measurement rooms, analysis rooms and other places
- Shell can be SS304/SS316L/carbon steel sprayed
- Whole unit can be customized upon request.
Product features
- Explosion-proof certification for whole unit, and the electrical& refrigeration components adopt a perfect combination of flameproof, intrinsically safe, and encapsulated types protection;
- Incoming call self-start function, which can realize fully automatic unattended operation;
- Support RS485 communication, which can realize unit networking (upon request);
- Dry contacts are reserved for the unit, which can realize functions such as fire interlocking;
- Appropriate design for various working environments, with a wide range of types and models, and cooling capacity. Can meet the needs of refrigeration, heating, dehumidification, positive pressure, ventilation and other special occasions with various explosive gases;
- Beautiful appearance and small size, simple and convenient installation and maintenance.
- Multiple function:cooling, heating, ventilation, dehumidification and other meet different need.
- Diversified installation: Floor standing duct type or wall-mounted type, horizontal ceiling mounted duct type, customized service.
Technical parameters
Model | BYTF-6YR | BYTF-8YR | BYTF-10YR | BYTF-12YR |
Cooling capacity(kW) | 8 | 8 | 10 | 12 |
Heating capacity (kW) | 6 | 9 | 9 | 12 |
Rated voltag(V) | AC 380V 50Hz | AC 380V 50Hz | AC 380V 50Hz | AC 380V 50Hz |
Fresh Air Flow(m³/h) | 190 | 300 | 350 | 400 |
Indoor safe Pressure Gap | 25~70Pa (adjustable) | 25~70Pa (adjustable) | 25~70Pa (adjustable) | 25~70Pa (adjustable) |
Temp. control range | 5℃~ 30℃ | 5℃~ 30℃ | 5℃~ 30℃ | 5℃~ 30℃ |
Size – L (mm) | 1000 | 1502 | 1502 | 1502 |
Size – W (mm) | 800 | 1002 | 1002 | 1002 |
Size – H (mm) | 2000 | 2170 | 2170 | 2170 |
Refrigerant | R22 | R22 | R22 | R22 |
Working ambient | T1 | T1 | T1 | T1 |
Case | Sprayed carbon steel | Sprayed carbon steel | Sprayed carbon steel | Sprayed carbon steel |
a) Control: temperature-regulating type, temperature-regulating and humidity-regulating type (optional)
b) Refrigerant: R22, R407C, R134a (optional).
c) Environmental working conditions: T1, T3, ultra-high temperature working conditions (optional)
d) Human-computer interaction interface: explosion-proof text screen, explosion-proof touch screen (optional).
e) Air supply and return mode: front air supply before return air type, upper air supply before return air type (optional).
f) Heat exchanger: copper tube with aluminum fin, copper tube with copper fin (optional).
g) Shell material: carbon steel sprayed plastic, SUS304, SUS316L (optional).
h) Optional Installation: Floor standing/wall mounted duct type, horizontal ceiling mounted duct type
The technical parameters of this catalogue are subject to update without notice.
Product applications reference
![](https://cctvex-china.com/wp-content/uploads/2024/07/Application-HVAC.jpg)
Typical Cases
![](https://cctvex-china.com/wp-content/uploads/2022/09/photobank-28-1.jpg)
Production
![](https://cctvex-china.com/wp-content/uploads/2022/09/生产.jpg)
Packing & Delivery
![](https://cctvex-china.com/wp-content/uploads/2022/09/发货-1.jpg)
Service
Product Period | Service |
Before sales | Inquiry and consulting support. Support professional ODM&OEM Can provide user requirement specification(URS) |
During production | Inquiry and consulting support. Support professional ODM&OEM Can provide user requirement specification(URS) |
After sales | Warranty & Maintenance: to replace defected parts during one(1) year of operations or eighteen(18) months from shipping,whichever comes first. |
Local service &showroom | Egypt, Russia, South Korea, UAE( Dubai) for limited model on contracting |
After Warranty Service | Will provide a lifetime technical support by video or online technical support. |
ABOUT YITONG
![](https://cctvex-china.com/wp-content/uploads/2023/08/16774881515381.jpg)
We have wide range explosion proof products of air conditioners, electrical control box, CCTV camera, lamp & light fixtures, electrical equipments, and box & fittings. Our products and projects occur in various occasions of petroleum, chemical and workshop across the world.We care the most of quality and stability of our products, as well as efficient communication and positive service to our customers and partners.
![](https://cctvex-china.com/wp-content/uploads/2018/12/2.jpg)
Nanyang Yitong is the registered supplier of China National Offshore Oil Corporation(COOC), China National Petroleum Corporation(CNPC), China Oilfield Services Limited(COSL), ABB(Switzerland),
Altrad Group(France), Hyundai Engineering Co., Ltd(Korea).etc. and we have exported many of explosion proof air conditioners and HVAC in Northeast Asia, Australia. We also have solo agent in UAE, Egypt, Russia and Korean.
![](https://cctvex-china.com/wp-content/uploads/2022/09/photobank-scaled.jpg)
Qualification
![](https://cctvex-china.com/wp-content/uploads/2024/07/photobank-27.jpg)
Exhibitions
![](https://cctvex-china.com/wp-content/uploads/2024/07/1.jpg)
FAQ
· Can you design a custom explosion proof solution for me?
- Yes! We have team engineers and designers that create custom solutions for our clients daily.
- Just contact email us as shown.
· What is explosion proof, and how do I determine what best suits my needs?
- The term “Explosion proof” is a generic term.
- Under the IEC, you will need to identify the following items for classification of your unit: Zones, Group(s) and T-Code (surface max. temperatures).
- Our company have the pre-sales service team that will help with your selection. If you need additional help on this, please call us. We look forward to hearing from you. Please note that cost and delivery can sometimes be effected by classification of your unit. Please confirm that your selection is correct for both safety and delivery issues.
· How do I get the unit shipped to my location?
- Simple.
- Wecan work with your freight forwarder or contract delivery of your units to a destination of your choice.we can ship your projects by land, sea, or air to any part of the world. we works closely with the best freight forwarders to get your project not only delivered on time, but also undamaged.
- Our shipping team can offer air or sea crating for your projects to keep the equipment in perfect working order.
· Do you ship equipment to the middle east?
- Yes, we ship orders worldwide.
